In this study, dissolvable microneedle (MN) arrays based on polyvinyl alcohol (PVA) were designed, fabricated, and evaluated for the controlled transdermal delivery of curcumin (Cur@MN). Fourier-Transform Infrared Spectroscopy (FTIR) confirmed the incorporation of curcumin within the PVA matrix, as evidenced by the presence of three characteristic peaks at 1510 cm⁻¹, 1603 cm⁻¹, and 1628 cm⁻¹. Optical and scanning electron microscopy revealed uniformly arranged, conical microneedles with sharp tips (<15 µm). Mechanical testing demonstrated successful penetration of five layers of Parafilm, indicating sufficient insertion strength for transdermal application. Drug release and degradation studies were conducted in phosphate-buffered saline (PBS, pH 7.4). The release profile exhibited an initial burst (60.31% within 12 hours), followed by sustained release up to 72 hours, reaching a cumulative release of 82.5%. Degradation tests showed faster structural breakdown in curcumin-loaded microneedles compared to unloaded ones. Furthermore, DPPH radical scavenging assays confirmed the significant antioxidant activity of Cur@MN, particularly at higher concentrations. These findings suggest that Cur@MN microneedles offer a promising, biocompatible platform for the transdermal delivery of natural therapeutics such as curcumin.
1. Anjani, Q. K., Nainggolan, A. D. C., Li, H., Miatmoko, A., Larrañeta, E., & Donnelly, R. F. (2024). Parafilm® M and Strat-M® as skin simulants in in vitro permeation of dissolving microarray patches loaded with proteins. International Journal of Pharmaceutics, 655, 124071. https://doi.org/10.1016/j.ijpharm.2024.124071
2. Borhan, S., Badr-Mohammadi, M. R., Hesaraki, S., & Esmaeilzadeh, J. (2021). Fabrication and Preliminary Characterization of Tissue Engineering Scaffolds Based on Alumina/Bioactive Glass. Advanced Ceramics Progress, 7(4), 10–19. https://doi.org/10.30501/acp.2022.323414.1079
3. Cao, W., Xia, D., Zhou, L., Liu, Y., Wang, D., Liang, C., & Chen, M. (2024). Antibacterial and antioxidant wound dressings with pH responsive release properties accelerate chronic wound healing. Materials Today Physics, 40, 101316. https:/doi.org/10.1016/j.mtphys.2023.101316
4. Chen, K., Pan, H., Ji, D., Li, Y., Duan, H., & Pan, W. (2021). Curcumin-loaded sandwich-like nanofibrous membrane prepared by electrospinning technology as wound dressing for accelerate wound healing. Materials Science and Engineering: C, 127, 112245. https:/doi.org/10.1016/j.msec.2021.112245
5. Chittasupho, C., Manthaisong, A., Okonogi, S., Tadtong, S., & Samee, W. (2021). Effects of quercetin and curcumin combination on antibacterial, antioxidant, in vitro wound healing and migration of human dermal fibroblast cells. International journal of molecular sciences, 23(1), 142. https://doi.org/10.3390/ijms23010142
6. Davidson, A., Al-Qallaf, B., & Das, D. B. (2008). Transdermal drug delivery by coated microneedles: Geometry effects on effective skin thickness and drug permeability. Chemical Engineering Research and Design, 86(11), 1196–1206. https:/doi.org/10.1016/j.cherd.2008.06.002
7. Dizaj, S. M., Kouhsoltani, M., Pourreza, K., Sharifi, S., & Abdolahinia, E. D. (2024). Preparation, Characterization, and Evaluation of the Anticancer Effect of Mesoporous Silica Nanoparticles Containing Rutin and Curcumin. Pharmaceutical Nanotechnology, 12(3), 269–275. https://doi.org/10.2174/2211738511666230818092706
8. Donnelly, R. F., Garland, M. J., Morrow, D. I. J., Migalska, K., Singh, T. R. R., Majithiya, R., & Woolfson, A. D. (2010). Optical coherence tomography is a valuable tool in the study of the effects of microneedle geometry on skin penetration characteristics and in-skin dissolution. Journal of Controlled Release, 147(3), 333–341. https:/doi.org/10.1016/j.jconrel.2010.08.008
9. Ebadi, T., Najafpour, G. D., Kazemi, S., & Hosseini, S. M. (2025). Development and In-vitro Evaluation of a Natural Polysaccharide Hydrogel for Curcumin Delivery. International Journal of Engineering, 38(5), 976–985. https://doi.org/10.5829/ije.2025.38.05b.02
10. Guo, W., Yang, M., Liu, S., Zhang, X., Zhang, B., & Chen, Y. (2021). Chitosan/polyvinyl alcohol/tannic acid multiple network composite hydrogel: preparation and characterization. Iranian Polymer Journal, 30(11), 1159–1168. https://doi.org/10.1007/s13726-021-00966-1
11. Jamaledin, R., Makvandi, P., Yiu, C. K. Y., Agarwal, T., Vecchione, R., Sun, W., Maiti, T. K., Tay, F. R., & Netti, P. A. (2020). Engineered Microneedle Patches for Controlled Release of Active Compounds: Recent Advances in Release Profile Tuning. Advanced Therapeutics, 3(12), 2000171. https://doi.org/10.1002/adtp.202000171
12. Larrañeta, E., Moore, J., Vicente-Pérez, E. M., González-Vázquez, P., Lutton, R., Woolfson, A. D., & Donnelly, R. F. (2014). A proposed model membrane and test method for microneedle insertion studies. International Journal of Pharmaceutics, 472(1), 65–73. https://doi.org/10.1016/j.ijpharm.2014.05.042
13. Li, X., Xiao, X., Zhang, Y., Long, R., Kankala, R. K., Wang, S., & Liu, Y. (2024). Microneedles based on hyaluronic acid-polyvinyl alcohol with antibacterial, anti-inflammatory, and antioxidant effects promote diabetic wound healing. International Journal of Biological Macromolecules, 282, 137185. https://doi.org/10.1016/j.ijbiomac.2024.137185
14. Mangang, K. N., Pragati, T., Jitu, H., Singh, Y. K., Goutam, G., Deepak, P., Goutam, R., & and Rai, V. K. (2023). PVP-microneedle array for drug delivery: mechanical insight, biodegradation, and recent advances. Journal of Biomaterials Science, Polymer Edition, 34(7), 986–1017. https://doi.org/10.1080/09205063.2022.2155778
15. Mao, S., Zeng, Y., Ren, Y., Ye, X., & Tian, J. (2025). Modification of physicochemical, antioxidant, and antibacterial properties of chitosan film with curcumin-loaded TA/Fe nanoparticles. Food Hydrocolloids, 160, 110722. https://doi.org/10.1016/j.foodhyd.2024.110722
16. McGuckin, M. B., Hutton, A. R. J., Davis, E. R., Sabri, A. H. B., Ripolin, A., Himawan, A., Naser, Y. A., Ghanma, R., Greer, B., McCarthy, H. O., Paredes, A. J., Larrañeta, E., & Donnelly, R. F. (2024). Transdermal Delivery of Pramipexole Using Microneedle Technology for the Potential Treatment of Parkinson’s Disease. Molecular Pharmaceutics, 21(5), 2512–2533. https://doi.org/10.1021/acs.molpharmaceut.4c00065
17. Paswan, M., Singh Chandel, A. K., Malek, N. I., & Dholakiya, B. Z. (2024). Preparation of sodium alginate/Cur-PLA hydrogel beads for curcumin encapsulation. International Journal of Biological Macromolecules, 254, 128005. https://doi.org/10.1016/j.ijbiomac.2023.128005
18. Prausnitz, M. R. (2004). Microneedles for transdermal drug delivery. Advanced Drug Delivery Reviews, 56(5), 581–587. https://doi.org/10.1016/j.addr.2003.10.023
19. Prausnitz, M. R., & Langer, R. (2008). Transdermal drug delivery. Nature Biotechnology, 26(11), 1261–1268. https://doi.org/10.1038/nbt.1504
20. Quelé, L. N. d. S., de Matos, M., de Lima, G. G., Brugnari, T., Ribeiro, C. S. P., Pedro, A. C., Gonzalez de Cademartori, P. H., & Magalhães, W. L. E. (2025). Antimicrobial and Antioxidant Properties of Photodegraded Amorphous Curcumin on Silica Nanoparticles. ACS Applied Nano Materials, 8(9), 4384–4396. https://doi.org/10.1021/acsanm.4c05159
21. Sabbagh, F., & Kim, B. S. (2023). Ex Vivo Transdermal Delivery of Nicotinamide Mononucleotide Using Polyvinyl Alcohol Microneedles. Polymers, 15(9), 2031. https://doi.org/10.3390/polym15092031
22. Singh, P., Carrier, A., Chen, Y., Lin, S., Wang, J., Cui, S., & Zhang, X. (2019). Polymeric microneedles for controlled transdermal drug delivery. Journal of Controlled Release, 315, 97–113. https://doi.org/10.1016/j.jconrel.2019.10.022
23. Valencia, M. S., Silva Júnior, M. F. d., Xavier-Júnior, F. H., Veras, B. d. O., Albuquerque, P. B. S. d., Borba, E. F. d. O., Silva, T. G. d., Xavier, V. L., Souza, M. P. d., & Carneiro-da-Cunha, M. d. G. (2021). Characterization of curcumin-loaded lecithin-chitosan bioactive nanoparticles. Carbohydrate Polymer Technologies and Applications, 2, 100119. https://doi.org/10.1016/j.carpta.2021.100119
24. Waghule, T., Singhvi, G., Dubey, S. K., Pandey, M. M., Gupta, G., Singh, M., & Dua, K. (2019). Microneedles: A smart approach and increasing potential for transdermal drug delivery system. Biomedicine & Pharmacotherapy, 109, 1249–1258. https://doi.org/10.1016/j.biopha.2018.10.078
25. Xiao, M., Zifeng, W., Yanru, A., Yingqi, D., Xinghao, W., & and Zhu, Z. (2024). Fabrication and mechanical modelling of dissolvable PVA/PVP composite microneedles with biocompatibility for efficient transdermal delivery of ibuprofen. Journal of Biomaterials Science, Polymer Edition, 35(9), 1439–1454. https://doi.org/10.1080/09205063.2024.2333627
26. Xu, Z., Han, S., Gu, Z., & Wu, J. (2020). Advances and impact of antioxidant hydrogel in chronic wound healing. Advanced Healthcare Materials, 9(5), 1901502. https://doi.org/10.1002/adhm.201901502
Koohikar,A. and Mehdinavaz Aghdam,R. (2025). Microfabrication and Characterization of PVA-Based Microneedle Arrays for Curcumin Delivery. Journal of Advanced Materials and Technologies, 14(2), 76-89. doi: 10.30501/jamt.2025.523415.1331
